Commercial Platinum

Features & Components Included

Standard Features:

  • Pre-wired electrical components certified to UL-508 & CSA C22.2 standards
  • Submersible DEF pump (1/2 HP)
  • Built-in dispenser w/20’ hose reel assembly
  • Pulse output included; Card reader compatible
  • Magnetic mis-fill prevention nozzle, swivel-breakaway & spare mag collar
  • Inventory level display with audible overfill alarm
  • HDPE primary tank with manway
  • All models include 110% Secondary Containment
  • Insulated FRP panels
  • Aesthetically pleasing, smooth, glossy white exterior finish
  • Conforms to ISO 22241-3,4 standards
  • Hinged roof w/pneumatic lifts (Except 3400G and greater)
  • Stainless steel piping
  • 2” Fill-port dry break adapter
  • Leak-proof press fittings & BSPP connections
  • Audible overfill alarm
  • Atmospheric vent w/protective screen
  • Forklift compatible base frame
  • 400-6,000 Gallon Storage Capacity



Optional Features:

  • Thermostatically controlled heater
  • Exhaust Fan
  • Low Level Warning Light
  • Control Room Light
  • Bolt-Down Anchoring Kit
  • Undercarriage Insulation
  • And much more! Call our sales team today for more options!
Capacity (Gallons) Weight (lbs) Dimensions (inches)
400 1050 48x69x103
500 1500 44x107x89
750 1700 44x125x99
1000 2000 48x132x110
1320 2300 46x159x110
2000 3000 73x197x94
3400 3900 93x192x107
6000 6200 110x231x126

Files For Download

SD-PLT-COM-S2 (Commercial Platinum – Wide Side Dispense)
SD-PLT-COM-S3 (Commercial Platinum – Wide End Dispense)
Commercial Platinum – Narrow – End Dispense (500g-1320g)
Commercial Platinum – Narrow – Side Dispense (500g-1320g)
Commercial Platinum Spec Sheet
